Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Pistol |
| Shut-off | Yes |
| Noise & Vibrations | |
|---|---|
| Sound pressure | 77 dB(A) |
| Sound standard | ISO15744 |
| Sound uncertainty | 3 dB(A) |
| Vibration value | < 2.5 m/s2 |
| Vibration standard | ISO28927-2 |
| Speed | |
|---|---|
| Free speed | 8,700 r/min |
| Pulse Unit Information | |
|---|---|
| Pulsing frequency CCW | 18–26 Hz |
| Fixed transducer torque CCW service | 42 Nm |
| Oil volume in full pulse unit | 6 |
| Pulse unit casing tightening torque | 20 Nm |
| X-Gauge diameter | 1.8 mm |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| EU directives | 2006/42/EC |
| EC standard | EN ISO 11148-6:2012 |
| UK legislation | S.I. 2008/1597 |
| UK standard | EN ISO 11148-6:2012 |
| Air Information | |
|---|---|
| Air consumption under load | 6 l/s |
| Air consumption under load | 13 cfm |
| Max working pressure | 7 bar |
| Max working pressure | 100 psi |
| Max working pressure | 100 psig |
| Nominal working pressure | 6.3 bar |
| Nominal working pressure | 91 psi |
| Dimension & Weight | |
|---|---|
| Air inlet thread | 1/4 inch |
| Bolt size | M6–M8 mm |
| CS distance | 23 mm |
| Length | 168 mm |
| Recommended hose size | 8 mm |
| Square drive | 1/4 inch |
| Weight | 0.9 kg |
| Weight | 2 lb |
| Torque | |
|---|---|
| Torque range max | 28 Nm |
| Torque range min | 15 Nm |
| Torque range max | 21 ft lb |
| Torque range min | 11 ft lb |
