Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Angle |
| Shut-off | Yes |
| Outgoing spindle | 1/4 inch |
| Noise & Vibrations | |
|---|---|
| Sound pressure | 78 dB(A) |
| Sound standard | ISO15744 |
| Sound uncertainty | 3 dB(A) |
| Vibration standard | ISO28927-2 |
| Vibration value | <2.5 m/s2 |
| Speed | |
|---|---|
| Free speed | 360 r/min |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| EC standard | ISO 11148-6 |
| EU directives | 2006/42/EC |
| WEEE | 0 |
| Air Information | |
|---|---|
| Air consumption at free speed | 7 l/s / 15 cfm |
| Recommended hose size | 8 mm |
| Air inlet thread | 1/4 inch |
| Max working pressure | 7 bar / 100 psi / 100 psig |
| Dimension & Weight | |
|---|---|
| Weight | 1.1 kg / 2.4 lb |
| Length | 309 mm |
| Angle head height | 45 mm |
| Angle head centre to side | 11 mm |
| Torque | |
|---|---|
| Torque range soft joint min | 6 Nm / 54 in lb |
| Torque range soft joint max | 15 Nm / 133 in lb |
