Technical Specifications
| Torque | |
|---|---|
| Max torque | 2550 Nm |
| Torque range max | 1400 Nm |
| Torque range min | 700 Nm |
| Speed | |
|---|---|
| Free speed | 4500 r/min |
| Air Information | |
|---|---|
| Air consumption | 45 l/s |
| Max working pressure | 6.3 bar |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| EU directives | 2006/42/EC |
| EC standard | ISO 11148-6 |
| UK legislation | S.I. 2008/1597 |
| UK standard | ISO 11148-6 |
| Design & Functions | |
|---|---|
| PRO | Yes |
| Noise & Vibrations | |
|---|---|
| Sound power | 106 dB(A) |
| Sound pressure | 95 dB(A) |
| Sound standard | ISO15744 |
| Sound uncertainty | 3 dB(A) |
| Vibration standard | ISO28927-2 |
| Vibration uncertainty | 7 m/s2 |
| Vibration value | 11,73 m/s2 |
| Dimension & Weight | |
|---|---|
| Air inlet thread | 1/2 in |
| Bolt size max | 32 mm |
| Bolt size min | 0 mm |
| Length | 277 mm |
| Rec. hose size | 19 mm |
| Square drive size | 1 in |
| Weight | 10.2 kg |
| Design | |
|---|---|
| Clutch type | Single hammer |
