Technical Specifications
| Air information | |
|---|---|
| Air consumption at load | 2.4 l/s |
| Air inlet thread size (in) | 1/4 |
| Max dynamic air working pressure | 6.3 bar |
| Min hose diam (16 ft hose length) | 0.38 in |
| Min hose diam (5 m hose length) | 10 mm |
| Design & Functions | |
|---|---|
| Blow per minute | 2400 |
| Energy | 1.8 J |
| Needle capacity | 19×1/8 (3) |
| Starting system | Lever |
| Size & Weight | |
|---|---|
| Bore diameter | 23.5 mm |
| Length (L) | 360 mm |
| Stroke | 11 mm |
| Weight | 2.35 kg |
| Noise & vibrations | |
|---|---|
| Sound Power | 97 dB(A) |
| Sound Pressure | 86 dB(A) |
| Uncertainty vibration-K | 2.2 m/s² |
| Vibration | 4.8 m/s² |
