Technical Specifications
| Air information | |
|---|---|
| Air consumption at load | 8.4 l/s |
| Air inlet thread size (in) | 1/4 |
| Air inlet thread type | NPT |
| Max dynamic air working pressure | 6.3 bar |
| Min hose diam (16 ft hose length) | 0.38 in |
| Min hose diam (5 m hose length) | 10 mm |
| Design & Functions | |
|---|---|
| Blow per minute | 1020 |
| Energy | 9.2 J |
| Main Material type | Steel |
| Starting system | Safety lever |
| Size & Weight | |
|---|---|
| Bore diameter | 22 mm |
| Butt diameter | 51 mm |
| Length (L) | 633 mm |
| Stroke | 64 mm |
| Weight | 3.3 kg |
| Noise & vibrations | |
|---|---|
| Sound Power | 106 dB(A) |
| Sound Pressure | 95 dB(A) |
| Uncertainty vibration-K | 5.4 m/s² |
| Vibration | 17.7 m/s² |
