CP4210AL

Part No: 6151710220

ALLIGATOR JAW PNEUMATIC RIVET SQUEEZER

The CP42 series includes six models of squeezers which covers the most frequently used rivets in metal structure repair for aerospace, and their functional design is truly first class. You have a choice between C-jaws and Alligator jaws to best fit your application and to give optimal access.Country of origin is TW. Customs tariff is 84671900

Compare
ADD TO QUOTE
Category:

Technical Specifications

Size & Weight
Height (H)134 mm
Length (L)273 mm
Moving plunger max. travel19.1 mm
Weight2.1 kg

Design & Functions
Jaw typeAligator long
Main Material typeAluminium
Max compression force (90psi/6.2bar)8 kN
Max rivet size aluminium (in)3/32
Max rivet size aluminium (mm)2.4
Max rivet size steel (in)1/16
Max rivet size steel (mm)1.6
Starting systemSafety lever

Noise & vibrations
Sound Power87 dB(A)
Sound Pressure76 dB(A)
Uncertainty vibration-K2.7 m/s²
Vibration (m/s²)<2.5 m/s**2

Air information
Air inlet thread size (in)1/4
Air inlet thread typeNPT
Max dynamic air working pressure6.3 bar
Min hose diam (16 ft hose length)0.38 in
Min hose diam (5 m hose length)9.5 mm
Weight2,91 kg
Dimensions32,5 × 16 × 13,5 cm
