Technical Specifications
Torque
| Max working torque fwd | 1290 Nm |
| Max torque reverse | 1630 Nm |
| Min working torque fwd | 350 Nm |
| Torque limited | No |
Air information
| Air inlet thread size (in) | 3/8 |
| Max dynamic air working pressure | 6.3 bar |
| Min hose diam (16 ft hose length) | 0.5 in |
| Min hose diam (5 m hose length) | 13 mm |
Noise & Vibrations
| Sound Power | 107 dB(A) |
| Sound Pressure | 96 dB(A) |
| Uncertainty vibration-K | 1.3 m/s² |
| Vibration (m/s²) | 9.4 |
| Vibration | 9.4 m/s² |
Speed
| Free Speed | 6300 rpm |
Size & Weight
| Length (L) | 222 mm |
| Power weight ratio | 290 Nm/kg |
| Side to Center | 41 mm |
| Weight | 5.5 kg |
Design & Functions
| Blow per minute | 900 |
| Body | Aluminium |
| Clutch housing | Steel |
| Clutch lubrication type | Oil bath |
| Handle type | Pistol |
| Impact mechanism | Twin hammer |
| Output drive size (in) | 3/4 |
| Output drive type | Sq |
| Output retainer type | Friction ring |
| Starting system | Trigger |
