Technical Specifications
| Size & Weight | |
|---|---|
| Length (L) | 163 mm |
| Weight | 0.6 kg |
| Speed | |
|---|---|
| Free Speed | 23000 rpm |
| Air consumption at free speed (Normo) | 9 l/sNl |
| Air consumption at free speed | 1.3 l/s |
| Air Information | |
|---|---|
| Air consumption at load | 1 l/s |
| Air inlet thread size (in) | 1/4 |
| Air inlet thread type | NPT |
| Max dynamic air working pressure | 6.3 bar |
| Min hose diam (16 ft hose length) | 0.38 in |
| Min hose diam (5 m hose length) | 10 mm |
| Noise & Vibrations | |
|---|---|
| Sound Power | 89.1 dB(A) |
| Sound Pressure | 78.1 dB(A) |
| Uncertainty vibration-K | 1.3 m/s² |
| Vibration | 5.4 m/s² |
| Tightening Strategies | |
|---|---|
| Angle Type | 90° |
| Power | |
|---|---|
| Max power | 250 W |
| Design & Functions | |
|---|---|
| Collet max capacity | 1/4 (6.35mm) |
| Exhaust | Rear |
| Main Material type | Aluminium, Composite over-sleeve |
| Rotative inlet | No |
| Spindle lock | Yes |
| Starting system | Safety lever |
