Technical Specifications
| Torque | |
|---|---|
| Max torque in forward | 900 Nm |
| Max torque reverse | 900 Nm |
| Min torque in forward | 450 Nm |
| Torque Control System | Shut-off-pneumatic valve |
| Design & Functions | |
|---|---|
| Adjustment | Key |
| Handle type | Pistol |
| Output drive size (in) | 1 |
| Output drive type | Sq |
| Output retainer type | Hole |
| Reaction bar type | Blade included |
| Reversible | Yes |
| Spline type | 0 |
| Starting system | Trigger |
| Size & Weight | |
|---|---|
| Length (L) | 345 mm |
| Weight | 6.6 kg |
| Speed | |
|---|---|
| Free Speed | 100 rpm |
| Air consumption at free speed | 19 l/s |
| Noise & vibrations | |
|---|---|
| Sound Power | 90 dB(A) |
| Sound Pressure | 79 dB(A) |
| Vibration (m/s²) | <2.5 |
| Air information | |
|---|---|
| Air inlet thread size (in) | 3/8 |
| Air inlet thread type | BSPP |
| Max dynamic air working pressure | 7 bar |
| Min hose diam (5 m hose length) | 13 mm |
