Technical Specifications
| Torque | |
|---|---|
| Max working torque fwd | 949 Nm |
| Max torque reverse | 1350 Nm |
| Min working torque fwd | 203 Nm |
| Torque limited | No |
| Air information | |
|---|---|
| Air inlet thread size (in) | 3/8 |
| Max dynamic air working pressure | 6.3 bar |
| Min hose diam (16 ft hose length) | 0.5 in |
| Min hose diam (5 m hose length) | 13 mm |
| Noise & vibrations | |
|---|---|
| Sound Power | 107 dB(A) |
| Sound Pressure | 96 dB(A) |
| Uncertainty vibration-K | 2 m/s² |
| Vibration (m/s²) | 5.8 |
| Vibration | 5.8 m/s² |
| Speed | |
|---|---|
| Free Speed | 4200 rpm |
| Size & Weight | |
|---|---|
| Length (L) | 245 mm |
| Power weight ratio | 280 Nm/kg |
| Weight | 4.76 kg |
| Design & Functions | |
|---|---|
| Blow per minute | 900 |
| Body | Aluminum |
| Clutch housing | Aluminum |
| Clutch lubrication type | Oil bath |
| Handle type | Pistol |
| Impact mecanism | Pin clutch |
| Output drive size (in) | 3/4 |
| Output drive type | Sq |
| Output retainer type | Friction ring |
| Starting system | Trigger |
