Technical Specifications
| Size & Weight | |
|---|---|
| Length (L) | 121 mm |
| Weight | 0.34 kg |
| Speed | |
|---|---|
| Free Speed | 30000 rpm |
| Air consumption at free speed | 11 l/s |
| Air Information | |
|---|---|
| Air consumption at load | 11 l/s |
| Air inlet thread size (in) | 1/4 |
| Air inlet thread type | NPT |
| Max dynamic air working pressure | 6.3 bar |
| Min hose diam (16 ft hose length) | 0.38 in |
| Min hose diam (5 m hose length) | 10 mm |
| Noise & Vibrations | |
|---|---|
| Sound Power | 112.3 dB(A) |
| Sound Pressure | 101.3 dB(A) |
| Vibration (m/s²) | <2.5 |
| Tightening Strategies | |
|---|---|
| Angle Type | Straight |
| Power | |
|---|---|
| Max power | 220 W |
| Design & Functions | |
|---|---|
| Collet max capacity | 1/4 (6.4mm) |
| Exhaust | Front |
| Governor type | NA |
| Main Material type | Aluminium, Composite over-sleeve |
| Rotative inlet | No |
| Spindle lock | No |
| Starting system | Safety lever |
