Technical Specifications
| Size & Weight | |
|---|---|
| Length (L) | 120 mm |
| Weight | 0.7 kg |
| Speed | |
|---|---|
| Free Speed | 17000 rpm |
| Air consumption at free speed | 7.5 l/s |
| Air information | |
|---|---|
| Air consumption at load | 8.5 l/s |
| Air inlet thread size (in) | 1/4 |
| Max dynamic air working pressure | 6.3 bar |
| Min hose diam (16 ft hose length) | 0.38 in |
| Min hose diam (5 m hose length) | 10 mm |
| Noise & vibrations | |
|---|---|
| Sound Power | 92 dB(A) |
| Sound Pressure | 81 dB(A) |
| Uncertainty vibration-K | 1.9 m/s² |
| Vibration | 3 m/s² |
| Tightening Strategies | |
|---|---|
| Angle Type | 90° |
| Power | |
|---|---|
| Max power | 150 W |
| Design & Functions | |
|---|---|
| Collet max capacity | 1/4 (6.4mm) |
| Exhaust | Rear |
| Governor type | NA |
| Main Material type | Aluminium, Composite over-sleeve |
| Rotative inlet | No |
| Spindle lock | No |
| Starting system | Trigger |
