Technical Specifications
| Design & Functions | |
|---|---|
| Blow per minute | 1700 |
| Chisel shank | Hex |
| Chisel shank diameter (in) | 0.580 |
| Chisel shank diameter (mm) | 14.7 |
| Main Material type | Steel |
| Starting system | Trigger |
| Noise & vibrations | |
|---|---|
| Sound Power | 110.9 dB(A) |
| Sound Pressure | 99.9 dB(A) |
| Uncertainty vibration-K | 2.9 m/s² |
| Vibration | 14.3 m/s² |
| Size & Weight | |
|---|---|
| Bore diameter | 29 mm |
| Length (L) | 425 mm |
| Stroke | 102 mm |
| Weight | 9.15 kg |
| Air information | |
|---|---|
| Air consumption at load | 15 l/s |
| Air inlet thread size (in) | 3/8 |
| Max dynamic air working pressure | 6.3 bar |
| Min hose diam (16 ft hose length) | 0.38 in |
| Min hose diam (5 m hose length) | 10 mm |
