Technical Specifications
| Size & Weight | |
|---|---|
| Height (H) | 115 mm |
| Length (L) | 280 mm |
| Width (W) | 280 mm |
| Max stroke length | 7 mm |
| Weight | 2.2 kg |
| Noise & vibrations | |
|---|---|
| Sound Power | 88.8 dB(A) |
| Sound Pressure | 77.8 dB(A) |
| Uncertainty vibration-K | 0.6 m/s² |
| Vibration | 2.5 m/s² |
| Design & Functions | |
|---|---|
| Main Material type | Aluminium, Composite over-sleeve |
| Max rivet size (mm) | M12 |
| Min rivet size (mm) | M3 |
| Mouthpiece delivered | 7 |
| Rivet type | Insert |
| Starting system | Trigger |
| Air information | |
|---|---|
| Air consumption at load | 2.8 l/s |
| Air inlet thread size (in) | 1/4 |
| Air inlet thread type | NPT |
| Max dynamic air working pressure | 6.3 bar |
| Min hose diam (5 m hose length) | 10 mm |
