Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Angle |
| Front type | Quick chuck |
| Collet size | 5 mm |
| Delivered collet size | 3.3 mm |
| Thread size | UNF 3/8" – 24 |
| Head angle | 90° |
| Power | |
|---|---|
| Power | 330 W |
| Power | 0.4 hp |
| Speed | |
|---|---|
| Free speed | 2000 r/min |
| Setting range min | 1500 r/min |
| Setting range max | 3200 r/min |
| Noise & Vibrations | |
|---|---|
| Sound pressure | 75 dB(A) |
| Vibration value | <2.5 m/s2 |
| Air Information | |
|---|---|
| Air consumption at free speed | 8.7 l/s |
| Air consumption at free speed | 18.4 cfm |
| Air inlet thread | 1/4 in |
| Recommended hose size | 1/4 in |
| Recommended hose size | 10 mm |
| Recommended hose size | 04 in |
| Dimension & Weight | |
|---|---|
| Length | 248 mm |
| Front length | 122 mm |
| Head height | 80 mm |
| Height | 40 mm |
| Diameter | 47 mm |
| Weight | 1.1 kg |
