The Atlas Copco EP6XS HR10 is a non-shut-off pneumatic pulse tool developed for professional fastening and industrial assembly applications. As part of the Atlas Copco ErgoPulse Non-shut-off range, it is designed for production environments that require efficient fastening, practical operator handling and reliable performance across repetitive assembly tasks.
Technical Specifications
| Dimension & Weight | |
|---|---|
| Air inlet thread | 1/4 in |
| Bolt size | M6 mm |
| CS distance | 22 mm |
| Length | 152 mm |
| Output size | 3/8″ |
| Recommended hose size | 8 mm |
| Square drive | 3/8 in |
| Weight | 0.8 kg |
| Speed | |
|---|---|
| Free speed | 8000 r/min |
| Air Information | |
|---|---|
| Air consumption under load | 8 l/s |
| Max working pressure | 7 bar |
| Nominal working pressure | 6.3 bar |
| Torque | |
|---|---|
| Pulse unit casing tightening Torque | 25 Nm |
| Torque range max | 20 Nm |
| Torque range min | 10 Nm |
| Noise & Vibrations | |
|---|---|
| Sound pressure | 79 dB(A) |
| Sound standard | ISO15744 |
| Sound uncertainty | 3 dB(A) |
| Vibration standard | ISO28927-2 |
| Vibration value | <2.5 m/s2 |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| EU directives | 2006/42/EC (MD) |
| EC standard | EN ISO 11148-6:2012 |
| UK legislation | S.I. 2008/1597 |
| UK standard | EN ISO 11148-6:2012 |
| Design & Functions | |
|---|---|
| Model type | Pistol |
| Output type | Square, Male |
| SCIP | 9e6972b2-2f4b-487b-bd1c-d051871d8321 |
| Shut-off | No |
Atlas Copco EP6XS HR10 ErgoPulse Non-Shut-Off Tool
The Atlas Copco EP6XS HR10 is a pistol-type non-shut-off pneumatic pulse tool designed for professional fastening and industrial assembly applications. It provides a torque range of 10–20 Nm and a free speed of 8,000 r/min, making it suitable for fastening operations where this torque capacity and operating speed match the assembly requirement.
The EP6XS HR10 is specified for M6 bolt size applications and uses a 3/8 inch male square output with a 3/8 inch square drive. The tool has an overall length of 152 mm, a CS distance of 22 mm and a weight of 0.8 kg, giving it a compact technical profile for repetitive fastening work and assembly stations where tool size and handling are important considerations.
For pneumatic operation, the model has a nominal working pressure of 6.3 bar and a maximum working pressure of 7 bar. Air consumption under load is 8 l/s, while the recommended hose size is 8 mm and the air inlet thread is 1/4 inch.
Applications
The Atlas Copco EP6XS HR10 is intended for industrial fastening applications requiring a 10–20 Nm torque range, M6 bolt size capability, 8,000 r/min free speed and 3/8 inch square drive. Its pistol configuration and compact dimensions make it suitable for assembly processes where these torque, speed, drive and access requirements correspond to the fastening task.
As a non-shut-off pulse tool, the EP6XS HR10 belongs to the Atlas Copco ErgoPulse – Non-shut-off range. Buyers can compare models in this category according to torque range, bolt size, output size, free speed, air requirements and physical dimensions.
Key Features
- Non-shut-off pneumatic pulse tool
- Pistol model configuration
- Torque range: 10–20 Nm
- Free speed: 8,000 r/min
- M6 bolt size
- 3/8 inch male square output
- 3/8 inch square drive
- Pulse unit casing tightening torque: 25 Nm
- Nominal working pressure: 6.3 bar
- Maximum working pressure: 7 bar
- Air consumption under load: 8 l/s
- Recommended hose size: 8 mm
- Air inlet thread: 1/4 inch
- Weight: 0.8 kg
- Length: 152 mm
- CS distance: 22 mm
Why Choose the Atlas Copco EP6XS HR10?
The Atlas Copco EP6XS HR10 combines a 10–20 Nm torque range with a free speed of 8,000 r/min and a compact 152 mm overall length. For buyers, the main selection points are whether the required fastening torque falls within this range, whether the M6 bolt size and 3/8 inch drive are compatible with the application, and whether the available compressed-air system can supply the required pressure and airflow.
Its 0.8 kg weight should also be considered for repetitive production work, particularly where operator handling, limited working space and access around the fastening point are important factors in tool selection.
Compressed-Air Requirements
The EP6XS HR10 operates at a nominal working pressure of 6.3 bar and a maximum working pressure of 7 bar. Air consumption under load is 8 l/s. Atlas Copco specifies an 8 mm recommended hose size together with a 1/4 inch air inlet thread.
Before installation, buyers should confirm that the compressed-air supply at the workstation can maintain the required pressure and airflow and that the hose and air connection are compatible with the tool.
Noise, Vibration and Standards
The EP6XS HR10 has a sound pressure level of 79 dB(A), measured according to ISO15744 with a sound uncertainty of 3 dB(A). Its listed vibration value is <2.5 m/s2 according to ISO28927-2.
The model is EAC certified. Its listed EC standard is EN ISO 11148-6:2012 and the applicable EU directive is 2006/42/EC (MD). UK legislation is listed as S.I. 2008/1597, with EN ISO 11148-6:2012 listed as the UK standard.
Related Atlas Copco Pneumatic Assembly Tools
Middle East ABC supplies a range of Atlas Copco Pneumatic Assembly Tools for professional fastening and industrial assembly requirements. Buyers looking for other pulse-tool configurations can also compare products within the ErgoPulse – Non-shut-off category according to torque range, speed, bolt size, drive size, air requirements and tool dimensions.
Atlas Copco EP6XS HR10 Availability
Contact Middle East ABC for technical product information, availability and quotation support for the Atlas Copco EP6XS HR10 and other Atlas Copco pneumatic assembly tools.
