The Atlas Copco ETD ST101-120-13-T25 is an industrial electric assembly tool designed for precise and repeatable fastening in professional production environments. It is intended for demanding assembly operations where consistent fastening performance and reliable process execution are required.
Technical Specifications
| Design & Functions | |
|---|---|
| Model Type | Straight |
| Tensor | ST |
| Square Drive | 1/2 inch |
| Spline/Mounting | – |
| Torque | |
|---|---|
| Torque Range Min | 30 Nm |
| Torque Range Max | 120 Nm |
| Torque Range Min | 22 ft lb |
| Torque Range Max | 88 ft lb |
| Speed & Motor | |
|---|---|
| Speed | 873 r/min |
| Motor Power | 1,500 W |
| Motor Voltage | 200 V |
| Motor Voltage Type | 3 a.c. |
| Dimensions & Weight | |
|---|---|
| Length | 656 mm |
| CS Distance | 30.5 mm |
| Weight | 3.3 kg |
| Weight | 7.3 lb |
| Noise | |
|---|---|
| Sound Pressure | <70 dB(A) |
| Sound Standard | ISO15744 |
| Certifications, Standards & Directives | |
|---|---|
| CCC Certified | Yes |
| EAC Certified | Yes |
| KC Certified | Yes |
| KC ID | R-REI-50A-ETVST101 |
| EC Standard | EN 61000-3-2:2006, EN 61000-3-3:2008, EN 61000-6-2:2005, EN 61000-6-3:2007, EN 61010-1 |
| EU Directives | 2006/42/EC, 2011/65/EU, 2014/30/EU |
| WEEE | 4 – Large equipment >50cm |
Applications
The Atlas Copco ETD ST101-120-13-T25 is intended for industrial assembly and fastening operations requiring a straight tool configuration and a torque range of 30–120 Nm. Its 873 r/min speed, Tensor ST platform and 1/2 inch square drive make it suitable for production environments where these fastening specifications are required.
Key Features
- Straight electric assembly tool configuration
- Tensor ST platform
- Torque range of 30–120 Nm (22–88 ft lb)
- 1/2 inch square drive
- Speed of 873 r/min
- 1,500 W motor power
- 200 V, 3 a.c. motor supply
- Tool weight of 3.3 kg (7.3 lb)
- Overall length of 656 mm
- CS distance of 30.5 mm
- Sound pressure below 70 dB(A) according to ISO15744
- CCC, EAC and KC certified
Why Choose the ETD ST101-120-13-T25?
The ETD ST101-120-13-T25 combines a 30–120 Nm torque range with an 873 r/min speed, straight configuration and 1/2 inch square drive. Its Tensor ST design, 1,500 W motor and 200 V 3 a.c. supply provide useful comparison points when selecting an Atlas Copco electric assembly tool for industrial fastening requirements within this torque range.
Explore more models in our Atlas Copco Electric Assembly Tools category to compare different torque ranges, speeds, drives and tool configurations.
Related Electric Assembly Tools
Middle East ABC offers a range of Atlas Copco electric assembly tools for different industrial fastening requirements. Compare the ETD ST101-120-13-T25 with other models in the Electric Assembly Tools category based on torque range, square drive, speed, motor specifications, dimensions and tool configuration.
Atlas Copco ETD ST101-120-13-T25 Supplier in UAE
Middle East ABC supplies the Atlas Copco ETD ST101-120-13-T25 in the UAE for industrial manufacturing and assembly applications. Contact our team for product availability, technical information and quotation support.
Explore the manufacturer’s complete range on the official Atlas Copco Electric Assembly Tools page.
