Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Pistol |
| Square drive | 3/8 inch |
| Tensor | SRB |
| Shut-off system | Transducer |
| Torque | |
|---|---|
| Torque range min | 6 Nm |
| Torque range max | 25 Nm |
| Torque range min | 4.4 ft lb |
| Torque range max | 18.4 ft lb |
| Speed & Motor | |
|---|---|
| Speed | 1,500 r/min |
| Motor power | 500 W |
| Motor voltage | 38.1 V |
| Motor voltage type | d.c. |
| Battery Information | |
|---|---|
| Battery | Li-Io 18/36 V |
| Type of battery | 1 Li-ion |
| Weight of battery | 7 g |
| Material contains a battery | Yes |
| Dimension & Weight | |
|---|---|
| Length | 223 mm |
| Height | 211 mm |
| Width | 74 mm |
| Weight | 1.15 kg |
| Weight | 2.535 lb |
| Weight incl. battery | 1.65 kg |
| Weight incl. battery | 3.638 lb |
| Noise & Vibrations | |
|---|---|
| Sound pressure | <80 dB(A) |
| Sound standard | ISO15744 |
| Sound uncertainty | 3 dB(A) |
| Vibration value | <12 m/s2 |
| Vibration standard | ISO28927-2 |
| Vibration uncertainty | 1.5 m/s2 |
| Certifications, Standards & Directives | |
|---|---|
| CCC certified | No |
| KC certified | Yes |
| ETL listed | Yes |
| ETL control number | 3008099 |
| ETL text | 1 – 60745-1, -2-2 |
| EU directives | 2006/42/EC, 2011/65/EU, 2014/30/EU, 2014/53/EU |
| EC standard | EN 300 328 V2.1.1, EN 300 440 V2.1.1, EN 301 893 V2.1.1, EN 301489-1 V2.1.1, EN 301489-17 V3.1.1, EN 50566:2017, EN 55014-1:2017, EN 55014-2:2015, EN 61000-6-1:2007, EN 61000-6-2:2005, EN 61000-6-3:2007+A1, EN 61000-6-4:2007+A1, EN 62841-1:2015, EN 62841-2-2:2015+AC1 |
| WEEE | 5 – Small equipment <50cm |
| Regulatory Identification | |
|---|---|
| FCC ID | PVH 0965 |
| CMIIT ID | 2018AJ0238 |
| IC ID | 5325A-0965 |
| KC ID | R-R-50A-SRB |
