Technical Specifications
| Torque | |
|---|---|
| Torque range max | 950 Nm |
| Torque range min | 285 Nm |
| Torque scatter 3s | < 5% |
| Power | |
|---|---|
| Motor power | 1500 W |
| Motor voltage type | d.c. |
| Motor voltage | 36 V |
| Speed | |
|---|---|
| Speed range max | 33 r/min |
| Battery Information | |
|---|---|
| Battery | Li-Io 36 V |
| Type of battery | 1 Li-ion |
| Weight incl. battery | 5.8 kg |
| Noise & Vibrations | |
|---|---|
| Sound pressure | <70 dB(A) |
| Sound standard | ISO15744 |
| Vibration standard | ISO28927-2 |
| Vibration value | <2.5 m/s? |
| Dimension & Weight | |
|---|---|
| Height | 239 mm |
| Length | 398 mm |
| Output size | 1" |
| Weight | 5 kg |
| Width | 74.5 mm |
| Design & Functions | |
|---|---|
| Model type | Pistol |
| Output type | Square, Male |
| SCIP | 68c2f2d6-c770-45dc-b4e1-5cfc88785683 |
| Shut-off system | Transducer |
| Tool family | SRB |
| Certifications, Standards & Directives | |
|---|---|
| CCC certified | No |
| CMIT ID | 2018AJ0238 |
| EAC certified | Yes |
| EU Legislation | (EU) 2022/30 | 2006/42/EC (MD) | 2011/65/EU (RoHS) | 2014/53/EU (RED) | 2015/863/EU (RoHS amendment) |
| EU Standard | EN 18031-1:2024 | EN 300 328 V2.2.2 | EN 300 440 V2.1.1 | EN 301 489-1 V2.1.1 | EN 301 489-17 V3.1.1 | EN 301 893 V2.1.1 | EN 50566:2017 | EN 61000-6-2:2019 | EN 61000-6-2:2005+AC:2005 | EN 61000-6-3:2007+A1:2011 | EN 61000-6-4:2007+A1:2011 | EN 62209-2:2010+AC:2019 | EN 62841-1:2015 + AC:2015 + A11:2022 | EN 62841-2-2:2014 + AC:2015 |
| ETL control number | 3008099 |
| ETL listed | Yes |
| ETL text | 6 – 62841-2-2 |
| EU SAR value | 0.49 W/kg |
| FCC ID | PVH0965 |
| KC certified | No |
| UK Regulations | S.I. 2008/1597 | S.I. 2012/3032 | S.I. 2017/1206 |
| UK Standard | EN 18031-1:2024 | EN 300 328 V2.2.2 | EN 300 440 V2.1.1 | EN 301 489-1 V2.1.1 | EN 301 489-17 V3.1.1 | EN 301 893 V2.1.1 | EN 50566:2017 | EN 61000-6-2:2019 | EN 61000-6-3:2007+A1:2011 | EN 61000-6-4:2007+A1:2011 | EN 62209-2:2010+AC:2019 | EN 62841-1:2015 + AC:2015 + A11:2022 | EN 62841-2-2:2014 + AC:2015 |
| WEEE | 5 – Small equipment <50cm |
