Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Angle |
| Communication type | W-LAN |
| Square drive | 1/2 inch |
| Shut-off system | Transducer |
| Tensor | SB |
| Torque | |
|---|---|
| Torque range max | 140 Nm |
| Torque range min | 28 Nm |
| Torque range max | 101.5 ft lb |
| Torque range min | 20.65 ft lb |
| Speed | |
|---|---|
| Free speed 9.6 V | 120 r/min |
| Battery & Motor | |
|---|---|
| Battery | Li-Io 30 V |
| Motor power | 1,500 W |
| Motor voltage | 30 V |
| Dimension & Weight | |
|---|---|
| Weight | 3.4 kg |
| Weight | 7.5 lb |
| Weight incl. bat. | 4.4 kg |
| Weight incl. bat. | 9.7 lb |
| Length | 593 mm |
| CS distance | 25 mm |
| Height | 65 mm |
| Noise & Vibrations | |
|---|---|
| Sound pressure | <70 dB(A) |
| Sound standard | ISO15744 |
| Vibration value | <2.5 m/s2 |
| Vibration standard | ISO28927-2 |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| EC standard | EN 60745-1:2009 A11:2010, EN 60745-2-2:2010, EN 61000-6-2:2005+AC:2005, EN 61000-6-4:2007+A1:2011, EN 300 328 V2.1.1, EN 301 489-1 V2.1.1, EN 301 489-17 V3.1.1, EN 300 440 V2.1.1 |
| ETL control number | 3008099 |
| ETL listed | Yes |
| FCC ID | PVH0941 |
| IC ID | 5325A-0941 |
| WEEE | 6 – Electrical and Electronic Tools |
| CMIIT ID | 2014AJ1502 |
| ETL text | 1 – 60745-1, -2-2 |
| EU directives | 2006/42/EC, 2011/65/EU, 2014/30/EU, 2014/53/EU |
| KC certified | No |
