The Atlas Copco ETV STB64-100-13-W is a Tensor STB cordless angle nutrunner designed for precise industrial tightening with a 20–100 Nm torque range. Its cordless configuration provides greater freedom of movement on production and assembly lines while supporting controlled, repeatable fastening performance in demanding industrial applications.
Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Angle |
| Square drive | 1/2 inch |
| Shut-off system | Transducer |
| Tensor | STB |
| Torque | |
|---|---|
| Torque range min | 20 Nm |
| Torque range max | 100 Nm |
| Torque range min | 15 ft lb |
| Torque range max | 72.5 ft lb |
| Speed & Motor | |
|---|---|
| Free speed 9.6 V | 170 r/min |
| Motor power | 1,500 W |
| Motor voltage | 30 V |
| Battery & Communication | |
|---|---|
| Battery | Li-Io 30 V |
| Type of battery | 1 Li-ion |
| Weight of battery | 95 g |
| Material contains a battery | Yes |
| Communication type | W-LAN |
| Noise & Vibrations | |
|---|---|
| Sound pressure | <70 dB(A) |
| Sound standard | ISO15744 |
| Vibration value | <2.5 m/s2 |
| Vibration standard | ISO28927-2 |
| Dimension & Weight | |
|---|---|
| Length | 556.7 mm |
| Height | 60.4 mm |
| Weight | 2.9 kg |
| Weight | 6.4 lb |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| ETL listed | Yes |
| ETL control number | 3008099 |
| ETL text | 1 – 60745-1, -2-2 |
| FCC ID | PVH0941 |
| IC ID | 5325A-0941 |
| CMIIT ID | 2014AJ1502 |
| KC certified | Yes |
| KC ID | R-R-50A-ETVSTB34 |
| WEEE | 4 – Large equipment >50cm |
| EC standard | EN 300 328 V2.1.1, EN 300 440 V2.1.1, EN 301 489-1 V2.1.1, EN 301 489-17 V3.1.1, EN 55014-1:2017, EN 55014-2:2015, EN 61000-6-2:2005+AC:2005, EN 61000-6-4:2007+A1:2011, EN 62841-1:2015, EN 62841-2-2:2014 + AC:2015 |
| EU directives | 2011/65/EU, 2014/30/EU, 2014/35/EU, 2014/53/EU |
Applications
The Atlas Copco ETV STB64-100-13-W is designed for controlled industrial tightening applications where higher torque, cordless mobility and repeatable fastening are required. Its 20–100 Nm torque range makes it suitable for demanding production and assembly operations, while the angle configuration helps operators access fastening points in restricted working areas.
Key Features
- 20–100 Nm torque range for medium- to high-torque industrial fastening
- Angle configuration for improved access during assembly operations
- Transducer shut-off system for controlled and repeatable tightening
- W-LAN communication for connected industrial assembly environments
- 30 V Li-Ion battery platform
- 170 r/min free speed
- 1/2-inch square drive
- Low vibration level of <2.5 m/s²
- Sound pressure below 70 dB(A)
Why Choose the ETV STB64-100-13-W?
The ETV STB64-100-13-W cordless nutrunner combines a maximum torque of 100 Nm with transducer-controlled tightening and cordless flexibility. It is suitable for industrial production lines where fastening accuracy, repeatability and operator freedom of movement are important.
Its W-LAN communication capability also supports connected assembly processes. If you are comparing different tightening systems for your production line, read our guide to cordless vs corded industrial assembly tools.
Related Cordless Assembly Tools
The Atlas Copco ETV STB64-100-13-W belongs to the Tensor STB cordless tightening range. Explore our complete selection of Atlas Copco cordless assembly tools to compare other models, torque ranges and configurations for industrial fastening applications.
Atlas Copco ETV STB64-100-13-W Supplier in UAE
Middle East ABC supplies the Atlas Copco ETV STB64-100-13-W in the UAE for industrial manufacturing and assembly applications. Contact our team for product availability, technical information and quotation support for this model and other Atlas Copco cordless tightening tools.
For more information about Atlas Copco’s current cordless tightening solutions, visit the official Atlas Copco Cordless Assembly Tools page.
