Technical Specifications
| Design & Functions | |
|---|---|
| Function | Focus |
| Electrical Information | |
|---|---|
| Rated voltage | 100-240 V |
| Rated voltage frequency | 50-60 Hz |
| Rated voltage type | a.c. |
| Max input current | 0.7 A |
| Material contains a battery | No |
| Type of battery | n/a |
| Environmental & Protection | |
|---|---|
| Environmental class | II |
| Ingress protection rating | IP21 |
| Min ambient temperature | 5 |
| Max ambient temperature | 40 °C |
| Dimensions | |
|---|---|
| Height | 219 mm |
| Height | 8.62 inch |
| Length | 121 mm |
| Length | 4.76 inch |
| Width | 147 mm |
| Width | 5.79 inch |
| Certifications, Standards & Directives | |
|---|---|
| CCC certified | Yes |
| EC standard | EN 61010-1:2010, EN 62311, ETSI EN 300 220-2, ETSI EN 301 489-3 |
| ETL control number | 5005940 |
| ETL listed | Yes |
| EU directives | 2014/53/EU |
| FCC ID | 2AEWD-F6X |
| Giteki certified | Yes |
| IC ID | 21556-F6X |
| KC certified | Yes |
| WEEE | 9 – Monitoring and Control Instruments |
