Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Pistol |
| Front type | Chuck |
| Chuck capacity range min | 0.8 mm |
| Chuck capacity range max | 6.5 mm |
| Thread size | UNF 3/8" – 24 |
| Power | |
|---|---|
| Power | 290 W |
| Speed | |
|---|---|
| Free speed | 3300 r/min |
| Noise & Vibrations | |
|---|---|
| Sound pressure | 80 dB(A) |
| Sound uncertainty | 3 dB(A) |
| Vibration value | <2.5 m/s2 |
| Air Information | |
|---|---|
| Air consumption at free speed | 8 l/s |
| Air consumption at free speed | 17 cfm |
| Air inlet thread | 1/4 in |
| Recommended hose size | 1/4 in |
| Recommended hose size | 6.3 mm |
| Max working pressure | 7 bar |
| Max working pressure | 100 psig |
| Dimension & Weight | |
|---|---|
| Length | 185 mm |
| Length | 7.28 in |
| Front length | 34 mm |
| Front length | 1.34 in |
| Height | 131 mm |
| Height | 5.16 in |
| Diameter | 33 mm |
| Weight | 0.6 kg |
