Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Pistol |
| Front type | Chuck |
| Chuck capacity range min | 0.5 mm |
| Chuck capacity range max | 6.5 mm |
| Thread size | UNF 3/8" – 24 |
| Torque | |
|---|---|
| Stall torque | 1.7 Nm |
| Power | |
|---|---|
| Power | 820 W |
| Speed | |
|---|---|
| Free speed | 23,000 r/min |
| Noise & Vibrations | |
|---|---|
| Sound pressure | 80 dB(A) |
| Sound uncertainty | 3 dB(A) |
| Vibration value | <2.5 m/s2 |
| Air Information | |
|---|---|
| Air consumption at free speed | 17 cfm |
| Air consumption at free speed | 8 l/s |
| Air inlet thread | 3/8 in |
| Recommended hose size | 3/8 in |
| Recommended hose size | 10 mm |
| Max working pressure | 7 bar |
| Max working pressure | 100 psig |
| Dimension & Weight | ||
|---|---|---|
| Length | 201 mm | |
| Front length | 331 mm | |
| Front length | 1.2 in | |
| Height | 160 mm | |
| Diameter | 42 mm | |
| style=”background: #f5f5f5;”> | Weight | 1 kg1 kg |
