Technical Specifications
| Design & Functions | |
|---|---|
| Unit type | Motor |
| Model type | Straight |
| Front type | Modular |
| Power | |
|---|---|
| Power | 300 W |
| Power | 0.4 hp |
| Speed | |
|---|---|
| Free speed | 1,000 r/min |
| Setting range min | 200 r/min |
| Setting range max | 500 r/min |
| Noise & Vibrations | |
|---|---|
| Sound uncertainty | 3 dB(A) |
| Air Information | |
|---|---|
| Air inlet thread | 1/4 in |
| Recommended hose size | 1/4 in |
| Recommended hose size | 6.3 mm |
| Max working pressure | 7 bar |
| Max working pressure | 100 psig |
| Dimension & Weight | |
|---|---|
| Length | 178 mm |
| Front length | 36 mm |
| Height | 42 mm |
| Diameter | 39 mm |
| Weight | 0.57 kg |
