Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Angle |
| Head type | Short |
| Head angle | 30° |
| Collet & Thread | |
|---|---|
| Collet size | 5 mm |
| Delivered collet size | 3.3 mm |
| Thread size | UNF 9/32" – 40 |
| Speed & Power | |
|---|---|
| Free speed | 2,900 r/min |
| Power | 110 W |
| Power | 0.16 hp |
| Noise | |
|---|---|
| Sound pressure | 72 dB(A) |
| Sound standard | ISO15744 |
| Air Information | |
|---|---|
| Air consumption at free speed | 8.5 cfm |
| Air consumption at free speed | 4 l/s |
| Air inlet thread | 1/8 in |
| Recommended hose size | 1/8 in |
| Recommended hose size | 5.0 mm |
| Max working pressure | 100 psig |
| Max working pressure | 7 bar |
| Dimension & Weight | |
|---|---|
| Length | 8.5 in |
| Length | 216 mm |
| Front length | 2.4 in |
| Front length | 61 mm |
| Diameter | 0.67 in |
| Diameter | 17 mm |
| Height | 1.18 in |
| Height | 30 mm |
| Head height | 1.1 in |
| Head height | 28 mm |
| Weight | 0.5 kg |
| Weight | 1.1 lb |
| Certifications, Standards & Directives | |
|---|---|
| EC standard | ISO 11148-3 |
