Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Angle |
| Front type | Threaded collet |
| Head type | Standard |
| Head angle | 45° |
| Collet & Thread | |
|---|---|
| Collet size | 5 mm |
| Delivered collet size | 3.3 mm |
| Thread size | UNF 9/32" – 40 |
| Speed & Power | |
|---|---|
| Free speed | 3,200 r/min |
| Setting range min | 1,500 r/min |
| Setting range max | 3,200 r/min |
| Power | 300 W |
| Power | 0.4 hp |
| Noise & Vibrations | |
|---|---|
| Sound pressure | 75 dB(A) |
| Sound uncertainty | 3 dB(A) |
| Vibration value | <2.5 m/s2 |
| Air Information | |
|---|---|
| Air consumption at free speed | 18.4 cfm |
| Air consumption at free speed | 8.7 l/s |
| Air inlet thread | 1/4 in |
| Recommended hose size | 1/4 in |
| Recommended hose size | 6.3 mm |
| Max working pressure | 100 psig |
| Max working pressure | 7 bar |
| Dimension & Weight | |
|---|---|
| Length | 10.94 in |
| Length | 278 mm |
| Front length | 5.51 in |
| Front length | 140 mm |
| Diameter | 0.67 in |
| Diameter | 17 mm |
| Height | 1.65 in |
| Height | 42 mm |
| Head height | 1.3 in |
| Head height | 33 mm |
| Weight | 0.5 kg |
| Weight | 1.1 lb |
