Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Angle |
| Front type | Collet |
| Head type | Standard |
| Head angle | 90° |
| Collet | |
|---|---|
| Collet size | 6.6 mm |
| Delivered collet size | 6 mm |
| Speed & Power | |
|---|---|
| Free speed | 3,000 r/min |
| Power | 510 W |
| Power | 0.73 hp |
| Noise & Vibrations | |
|---|---|
| Sound power | 92 dB(A) |
| Sound pressure | 81 dB(A) |
| Sound uncertainty | 3 dB(A) |
| Vibration value | <2.5 m/s2 |
| Air Information | |
|---|---|
| Air consumption at free speed | 36 cfm |
| Air consumption at free speed | 17 l/s |
| Air inlet thread | 1/4 in |
| Recommended hose size | 3/8 in |
| Recommended hose size | 10.0 mm |
| Max working pressure | 100 psig |
| Max working pressure | 7.0 bar |
| Dimension & Weight | |
|---|---|
| Length | 9.92 in |
| Length | 252 mm |
| Front length | 3.31 in |
| Front length | 84 mm |
| Diameter | 0.79 in |
| Diameter | 20 mm |
| Height | 1.69 in |
| Height | 43 mm |
| Head height | 1.57 in |
| Head height | 40 mm |
| Weight | 1.0 kg |
| Weight | 2.2 lb |
