Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Straight |
| Reversible | No |
| Shut-off | Yes |
| Noise & Vibrations | |
|---|---|
| Sound pressure | 79 dB(A) |
| Sound standard | ISO15744 |
| Sound uncertainty | 3 dB(A) |
| Speed | |
|---|---|
| Free speed | 820 r/min |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| EC standard | ISO 11148-6 |
| EU directives | 2006/42/EC |
| WEEE | 0 |
| Air Information | |
|---|---|
| Air consumption at free speed | 20 l/s / 42 cfm |
| Air inlet thread | 1/4 inch |
| Recommended hose size | 10 mm |
| Max working pressure | 7 bar / 100 psi |
| Dimension & Weight | |
|---|---|
| Bolt size | M8 mm |
| Square drive | 1/2 inch |
| Length | 521 mm |
| CS distance | 20 mm |
| Weight | 2.3 kg / 5 lb |
| Torque | |
|---|---|
| Torque range soft joint min | 14 Nm / 10 ft lb |
| Torque range soft joint max | 30 Nm / 21 ft lb |
