LTV39-2 R56-13-ATEX

Country of origin is SE. Customs tariff is 84671190
The Angle Nutrunner LTV range from Atlas Copco successfully combines two key performance factors ? speed and accuracy. Consistently accurate, high-speed tightening complemented by advanced ergonomic design the nutrunner ensures an unmatched level of productivity. Its lightweight design, durable long-life grip and low reaction force make it exceptionally easy to work with.

Compare
SEND INQUIRY
SKU: 8431063551 Category:





Technical Specifications


Technical Specifications

Design & Functions
Model typeAngle
Output typeSquare, Male
ReversibleYes
SCIP512325c7-97f9-4ab7-9ad4-7c27c003eb75
Shut-offYes

Dimension & Weight
Air inlet thread1/4 in
Angle head centre to side20 mm
Angle head height41 mm
Bolt sizeM10 mm
Length425 mm
Output size1/2″
Recommended hose size10 mm
Square drive1/2 in
Weight2 kg

Speed
Free speed460 r/min

Air Information
Air consumption at free speed16 l/s
Max working pressure7 bar

Torque
Max torque at 6.3 bar soft joint56 Nm
Min torque at 6.3 bar soft joint28 Nm
Torque range max56 Nm
Torque range min28 Nm

Noise & Vibrations
Sound power92 dB(A)
Sound pressure81 dB(A)
Sound standardISO15744
Sound uncertainty3 dB(A)
Vibration standardISO28927-2
Vibration value<2.5 m/s?

Certifications, Standards & Directives
ATEX codeEX II 3 GD IIB 135?C (T4)
ATEXYes
EAC certifiedYes
EU directives2006/42/EC
EC standardEN 80079-36:2016
UK legislationS.I. 2008/1597
UK standardEN 80079-36:2016


Weight2,33 kg
Dimensions58,3 × 10,6 × 8,8 cm
