Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Angle |
| Shut-off | Yes |
| Reversible | No |
| Torque | |
|---|---|
| Torque range soft joint min | 80 Nm |
| Torque range soft joint max | 230 Nm |
| Torque range soft joint min | 103 ft lb |
| Torque range soft joint max | 273 ft lb |
| Min torque at 3 bar soft joint | 140 Nm |
| Min torque at 3 bar soft joint | 59 ft lb |
| Min torque at 6.3 bar soft joint | 190 Nm |
| Min torque at 6.3 bar soft joint | 140 ft lb |
| Max torque at 6.3 bar soft joint | 230 Nm |
| Max torque at 6.3 bar soft joint | 170 ft lb |
| Speed | |
|---|---|
| Free speed | 320 r/min |
| Air Information | |
|---|---|
| Air consumption at free speed | 20 l/s |
| Air consumption at free speed | 42 cfm |
| Recommended hose size | 13 mm |
| Air inlet thread | 1/2 inch |
| Max working pressure | 7 bar |
| Max working pressure | 100 psig |
| Dimension & Weight | |
|---|---|
| Bolt size | M16 mm |
| Weight | 4 kg |
| Length | 535 mm |
| Angle head height | 62 mm |
| Angle head centre to side | 32.9 mm |
