Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Angle |
| Output type | Square, Male |
| Reversible | No |
| SCIP | 512325c7-97f9-4ab7-9ad4-7c27c003eb75 |
| Shut-off | Yes |
| Dimension & Weight | |
|---|---|
| Air inlet thread | 1/2 in |
| Angle head centre to side | 32.9 mm |
| Angle head height | 62 mm |
| Bolt size | M18 mm |
| Length | 619 mm |
| Output size | 3/4″ |
| Recommended hose size | 13 mm |
| Square drive | 3/4 in |
| Weight | 7.1 kg |
| Speed | |
|---|---|
| Free speed | 480 r/min |
| Air Information | |
|---|---|
| Air consumption at free speed | 20 l/s |
| Max working pressure | 7 bar |
| Torque | |
|---|---|
| Max torque at 6.3 bar soft joint | 370 Nm |
| Min torque at 3 bar soft joint | 140 Nm |
| Min torque at 6.3 bar soft joint | 190 Nm |
| Torque range max | 370 Nm |
| Torque range min | 140 Nm |
| Noise & Vibrations | |
|---|---|
| Sound power | 91 dB(A) |
| Sound pressure | 80 dB(A) |
| Sound standard | ISO15744 |
| Sound uncertainty | 3 dB(A) |
| Vibration standard | ISO28927-2 |
| Vibration value | <2.5 m/s? |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| EU directives | 2006/42/EC |
| EC standard | ISO 11148-6 |
| UK legislation | S.I. 2008/1597 |
| UK standard | ISO 11148-6 |
