Technical Specifications
| Dimension & Weight | |
|---|---|
| Air inlet thread | 1/4 in |
| CS distance | 18.5 mm |
| Length | 195 mm |
| Output size | Special design |
| Recommended hose size | 6 mm |
| Weight | 0.7 kg |
| Noise & Vibrations | |
|---|---|
| Sound pressure | 78 dB(A) |
| Sound standard | ISO15744 |
| Sound uncertainty | 3 dB(A) |
| Vibration standard | ISO28927-3 |
| Vibration value | <2.5 m/s2 |
| Design & Functions | |
|---|---|
| Model type | Straight |
| Output type | Special design |
| SCIP | 47e16caf-a521-4999-9f5a-5ea995d62d14 |
| Shut-off | Direct drive |
| Start trigger | Trigger lever |
| Speed | |
|---|---|
| Free speed | 700 r/min |
| Air Information | |
|---|---|
| Air consumption at free speed | 8 l/s |
| Max working pressure | 7 bar |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| EU directives | 2006/42/EC (Annex I, clauses 1.1, 1.6, 1.7, 2.2.1) |
| EC standard | EN ISO 11148-6:2012 |
| UK legislation | S.I. 2008/1597 (Annex I, clauses 1.1, 1.6, 1.7, 2.2.1) |
| UK standard | BS EN ISO 11148-6:2012 |
| Torque | |
|---|---|
| Torque range max | 10 Nm |
| Torque range min | 5 Nm |
| Torque range soft joint max | 10 Nm |
| Torque range soft joint min | 5 Nm |
