Industrial Air Motors: LZL05-BF322-A-012. It belongs to the Atlas Copco Industrial Air Motors range.
Technical Specifications
| Speed | |
|---|---|
| Free speed | 680 r/min |
| Design & Functions | |
| Built in brake | No |
| Mounting arrangement | Foot |
| Ratio | 12.3 |
| Rotation direction | Reversible |
| SCIP | b70d15fd-8301-4fea-893a-db481d215b0e |
| Shaft type | Keyed |
| Vane type | Standard |
| Air information | |
| Air consumption at max output | 77 cfm |
| Air consumption at max output | 36 l/s |
| Dimension & weight | |
| Weight | 14 kg |
| Weight | 31 lb |
| Certifications, standards & directives | |
| ATEX | No |
| EU Legislation | 2006/42/EC (Annex I, clauses 1.1, 1.2 (excluding 1.2.4.3), 1.3, 1.4, 1.5, 1.6, 1.7) |
| EU Standard | EN ISO 12100:2010 |
| UK Regulations | S.I. 2008/1597 (Annex I, clauses 1.1, 1.2 (excluding 1.2.4.3), 1.3, 1.4, 1.5, 1.6, 1.7) |
| UK Standard | BS EN ISO 12100:2010 |
| Material | |
| External parts material | Powder coated cast iron/Aluminium |
| Torque | |
| Min starting torque | 37 ft-lb |
| Min starting torque | 51 Nm |
| Stall torque | 44 ft-lb |
| Stall torque | 60 Nm |
| Torque at max output | 22 ft-lb |
| Torque at max output | 30 Nm |
| Power | |
| Max output | 1.7 hp |
| Max output | 1.2 kW |
| Max radial load at max output | 2360 N |
| Speed at max output | 391 r/min |
