Technical Specifications
| Speed | |
|---|---|
| Max free speed range | 5500 rpm |
| Design & Functions | |
|---|---|
| Back Head Coaxial | No |
| Front nut threaded | Yes |
| Main Material type | Stainless steel |
| Motor Lubrication free | Yes |
| Rotation drive | Clockwise |
| Shaft loading code | b |
| Spindle type | Keyed shaft |
| Starting system | None |
| Torque | |
|---|---|
| Minimum starting torque | 2.3 Nm |
| Stall torque | 2.4 Nm |
| Torque at max power | 1.2 Nm |
| Air information | |
|---|---|
| Air consumption at load | 5.3 l/s |
| Air flow max power | 5.3 l/s |
| Air inlet thread size (in) | 1/8 |
| Air inlet thread type | BSP |
| Max dynamic air working pressure | 6.3 bar |
| Power | |
|---|---|
| Max output power | 0.3 kW |
| Size & Weight | |
|---|---|
| Output Spindle size | 10 mm |
| Weight | 0.71 kg |
