Technical Specifications
| Design & Functions | |
|---|---|
| Model type | Straight |
| PRO | Yes |
| Quick change chuck | 1/4 inch |
| Screw capacity min | 3 mm |
| Torque | |
|---|---|
| Torque range soft joint min | 0.5 Nm |
| Torque range soft joint max | 2 Nm |
| Speed | |
|---|---|
| Free speed | 1,300 r/min |
| Noise & Vibrations | |
|---|---|
| Sound power | 94 dB(A) |
| Sound pressure | 83 dB(A) |
| Sound standard | ISO15744 |
| Sound uncertainty | 3 dB(A) |
| Vibration standard | ISO28927-2 |
| Vibration value | <2.5 m/s2 |
| Air Information | |
|---|---|
| Air consumption at free speed | 4 l/s |
| Air inlet thread | 1/4 inch |
| Recommended hose size | 6.3 mm |
| Max working pressure | 7 bar |
| Max working pressure | 100 psig |
| Dimension & Weight | |
|---|---|
| Length | 250 mm |
| Weight | 0.9 kg |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| EC standard | ISO 11148-6 |
| EU directives | 2006/42/EC |
| WEEE | 0 |
