The Atlas Copco S8160 is an industrial electric assembly tool designed for precise and repeatable fastening operations in professional production environments. It is developed for applications requiring reliable torque control, consistent assembly performance and dependable fastening results across demanding industrial operations.
Technical Specifications
| Design & Functions | |
|---|---|
| Model Type | Straight |
| Square Drive | 1/4 inch |
| Screw Capacity | 2,0 to 4,2 mm for machine screw & 2,0-3.2mm for tapping screw |
| Torque | |
|---|---|
| Torque Range Min | 19.6 cNm |
| Torque Range Max | 156.9 cNm |
| Torque Range Min | 1.7 in lb |
| Torque Range Max | 13.9 in lb |
| Torque Range Min | 0.196 Nm |
| Torque Range Max | 1.569 Nm |
| Speed & Motor | |
|---|---|
| Free Speed | 1,000 r/min |
| Motor Power | 60 W |
| Electrical Data | |
|---|---|
| Motor Voltage | 30 V |
| Motor Voltage Type | d.c. |
| Dimensions & Weight | |
|---|---|
| Weight | 0.412 kg |
| Weight | 0.9 lb |
| Length | 227 mm |
| Noise | |
|---|---|
| Sound Pressure | 67 dB(A) |
| Certifications, Standards & Directives | |
|---|---|
| CCC Certified | No |
| KC Certified | No |
| EC Standard | EN 62841-1:2015 EN 62841-2-2:2015+AC EN 61000-6-4: 2007 + A1: 2011 EN 61000-6-2: 2005 / AC: 2005 EN 61000-3-2: 2014 EN 61000-3-3: 2013 |
| EU Directives | 2006/42/EU (MD) 2014/30/EU (EMC) 2011/65/EU (RoHS) |
| UK Legislation | S.I. 2008/1597, S.I. 2012/3032, S.I. 2016/1091 |
| UK Standard | EN 62841-1:2015 EN 62841-2-2:2015+AC EN 61000-6-4: 2007 + A1: 2011 EN 61000-6-2: 2005 / AC: 2005 EN 61000-3-2: 2014 EN 61000-3-3: 2013 |
| WEEE | 5 – Small equipment <50cm |
Atlas Copco S8160 Description
The Atlas Copco S8160 is a Straight electric assembly tool with a torque range of 0.196–1.569 Nm (19.6–156.9 cNm / 1.7–13.9 in lb). The S8160 operates at a free speed of 1,000 r/min with a 60 W motor and 30 V motor voltage. Its Straight model configuration and 1/4 inch square drive provide the specified tool configuration for industrial assembly requirements.
The tool weighs 0.412 kg (0.9 lb) and has a length of 227 mm. Its specified screw capacity is 2,0 to 4,2 mm for machine screw and 2,0-3.2mm for tapping screw. Sound pressure is rated at 67 dB(A).
Applications
The Atlas Copco S8160 can be selected for industrial assembly requirements where its 0.196–1.569 Nm torque range, 1,000 r/min free speed, Straight configuration, 1/4 inch square drive and specified screw capacity match the required fastening process.
Key Features
- Straight model configuration
- Torque range: 0.196–1.569 Nm
- Torque range: 19.6–156.9 cNm
- Torque range: 1.7–13.9 in lb
- Free speed: 1,000 r/min
- Motor power: 60 W
- Motor voltage: 30 V
- Motor voltage type: d.c.
- Square drive: 1/4 inch
- Screw capacity: 2,0 to 4,2 mm for machine screw & 2,0-3.2mm for tapping screw
- Weight: 0.412 kg / 0.9 lb
- Length: 227 mm
- Sound pressure: 67 dB(A)
- CCC certified: No
- KC certified: No
Why Choose the Atlas Copco S8160?
The Atlas Copco S8160 combines a 0.196–1.569 Nm torque range with 1,000 r/min free speed, a 60 W motor and 1/4 inch square drive. Its supplied technical data also includes a 0.412 kg weight, 227 mm length and specified screw capacity for machine and tapping screws.
CCC certified and KC certified are listed as No. Its supplied EC standards are EN 62841-1:2015, EN 62841-2-2:2015+AC, EN 61000-6-4: 2007 + A1: 2011, EN 61000-6-2: 2005 / AC: 2005, EN 61000-3-2: 2014 and EN 61000-3-3: 2013. The listed EU directives are 2006/42/EU (MD), 2014/30/EU (EMC) and 2011/65/EU (RoHS). UK legislation is listed as S.I. 2008/1597, S.I. 2012/3032 and S.I. 2016/1091, with the supplied UK standards EN 62841-1:2015, EN 62841-2-2:2015+AC, EN 61000-6-4: 2007 + A1: 2011, EN 61000-6-2: 2005 / AC: 2005, EN 61000-3-2: 2014 and EN 61000-3-3: 2013.
