Technical Specifications
| Design & Functions | |
|---|---|
| Function | Slip-clutch |
| Model type | Straight |
| Output type | Hexagon, Female |
| SCIP | 246d0aa9-e82e-44b8-8427-2cd21c43a003 |
| Shut-off | Slip-clutch |
| Start trigger | Trigger and push |
| Dimension & Weight | |
|---|---|
| Air inlet thread | G1/4" in |
| CS distance | 19 mm |
| Length | 154 mm |
| Outgoing spindle | 5/16 in |
| Output size | 1/4" |
| Recommended hose size | 8 mm |
| Weight | 0.8 kg |
| Noise & Vibrations | |
|---|---|
| Sound pressure | 78 dB(A) |
| Sound standard | ISO15744 |
| Sound uncertainty | 3 dB(A) |
| Vibration standard | ISO28927-2 |
| Vibration value | <2.5 m/s2 |
| Speed | |
|---|---|
| Free speed | 260 r/min |
| Air Information | |
|---|---|
| Air consumption at free speed | 8 l/s |
| Max working pressure | 7 bar |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| EU directives | 2006/42/EC (Annex I, clauses 1.1, 1.6, 1.7, 2.2.1) |
| EC standard | EN ISO 11148-6:2012 |
| UK legislation | S.I. 2008/1597 (Annex I, clauses 1.1, 1.6, 1.7, 2.2.1) |
| UK standard | BS EN ISO 11148-6:2012 |
| Torque | |
|---|---|
| Torque range max | 12 Nm |
| Torque range min | 6 Nm |
| Torque range soft joint max | 12 Nm |
| Torque range soft joint min | 6 Nm |
