Technical Specifications
| Design & Functions | |
|---|---|
| Function | Slip-clutch |
| Model type | Pistol balanced |
| Output type | Hexagon, Female |
| SCIP | 246d0aa9-e82e-44b8-8427-2cd21c43a003 |
| Shut-off | Slip-clutch |
| Start trigger | Trigger and push |
| Dimension & Weight | |
|---|---|
| Air inlet thread | 1/8 in |
| CS distance | 15 mm |
| Length | 186 mm |
| Output size | 1/4" |
| Recommended hose size | 6 mm |
| Weight | 0.65 kg |
| Noise & Vibrations | |
|---|---|
| Sound pressure | 80 dB(A) |
| Sound standard | ISO15744 |
| Sound uncertainty | 3 dB(A) |
| Vibration standard | ISO28927-2 |
| Vibration value | <2.5 m/s2 |
| Speed | |
|---|---|
| Free speed | 800 r/min |
| Air Information | |
|---|---|
| Air consumption at free speed | 6.5 l/s |
| Max working pressure | 7 bar |
| Certifications, Standards & Directives | |
|---|---|
| EAC certified | Yes |
| EU directives | 2006/42/EC |
| EC standard | ISO 11148-6 |
| UK legislation | S.I. 2008/1597 |
| UK standard | ISO 11148-6 |
| Torque | |
|---|---|
| Torque range max | 4.4 Nm |
| Torque range min | 0.5 Nm |
| Torque range soft joint max | 4.4 Nm |
| Torque range soft joint min | 0.5 Nm |
