Description
8431 0375 40
Technical Specifications
| Air inlet thread | 1/4 in | |
| Bolt size | M10 mm | |
| CS distance | 29 mm | |
| Length | 188 mm | |
| Recommended hose size | 10 mm | |
| Square drive | 1/2 in | |
| Weight | 3.3 lb | |
| Air consumption under load | 23 cfm | |
| Max working pressure | 100 psig | |
| Nominal working pressure | 91 psi | |
| Sound pressure | 82 dB(A) | |
| EAC certified | Yes | |
| EU directives | 2006/42/EC | |
| EC standard | EN ISO 11148-6:2012 | |
| Torque range max | 59 ft-lb | |
| Torque range min | 37 ft-lb | |
| Model type | Pistol | |
| Shut-off | Yes | |
| Free speed | 5200 r/min | |
| Sound standard | ISO15744 | |
| Sound uncertainty | 3 dB(A) | |
| Vibration standard | ISO28927-2 | |
| Vibration value | 5.6 m/s² |
