Technical Specifications
| Torque | |
|---|---|
| Max torque in forward | 2600 Nm |
| Max torque reverse | 2600 Nm |
| Min torque in forward | 700 Nm |
| Torque Control System | Non shut-off-stall |
| Design & Functions | |
|---|---|
| Accuracy (%) | ±5 % |
| Adjustment | Torque Chart |
| Handle type | Pistol |
| Joint Type | Hard & Soft |
| Main Material type | Composite |
| Output drive size (in) | 1 |
| Output drive type | Sq |
| Output retainer type | Hole |
| Reaction bar type | S-type |
| Reversible | Yes |
| Spline type | 47 |
| Starting system | Trigger |
| Suspension option | Optional |
| Size & Weight | |
|---|---|
| Height (H) | 212 mm |
| Length (L) | 300 mm |
| Width (W) | 72 mm |
| Side to Center | 34 mm |
| Weight | 5.1 kg |
| Weight without reaction arm | 5.1 kg |
| Weight with reaction arm | 6.5 kg |
| Speed | |
|---|---|
| Free Speed | 10 rpm |
| Air consumption at free speed | 23 l/s |
| Noise & vibrations | |
|---|---|
| Sound Power | 101 dB(A) |
| Sound Pressure | 90 dB(A) |
| Vibration (m/s²) | <2.5 |
| Vibration | 2.8 m/s² |
| Air information | |
|---|---|
| Air inlet thread size (in) | 3/8 |
| Air inlet thread type | NPT |
| Max dynamic air working pressure | 6.3 bar |
| Min hose diam (5 m hose length) | 16 mm |
