CP785S

T023200

Pneumatic shears

Technical Specifications

Blade lenght:22 mm

Cutting capacity aluminum:2 mm

Cutting capacity steel:1.3 mm

Length (L):229 mm

Stroke:2.2 mm

Weight:0.86 kg

Sound Power:84 dB(A)

Sound Pressure:95 dB(A)

Uncertainty vibration-K:3 m/s²

Vibration:3.2 m/s²

Air consumption at load:7.3 l/s

Air inlet thread size (in):1/4

Max dynamic air working pressure:6.3 bar

Min hose diam (16 ft hose length):0.38 in

Min hose diam (5 m hose length):10 mm

Application: Metallic

Stroke per minute:2400

Max power:258 W
