CP2822

6151630090

1/4" HEX STRAIGHT CUSHION PNEUMATIC SCREWDRIVER

The CP2816/CP2817 Series are 1/4" hex pistol cushion clutch screwdrivers designed for your heavy duty applications.
Well-balanced and lightweight design based on rugged aluminum housing with a comfortable rubber grip to ensure operator comfort.
Available in 2 free speed levels: 800 rpm CP2817 and 1900 rpm CP2816.
Country of origin is HU. Customs tariff is 84671190

SEND INQUIRY
Category:

Technical Specifications

Torque
Max torque in forward 6 Nm
Min torque in forward 2 Nm
Torque Control System Non shut-off clutch

Design & Functions
Adjustment Key
Body Aluminum
Clutch housing Steel
Clutch Type Cushion clutch
Handle type Pistol
Main Material type Aluminium, Composite over-sleeve
Output drive size (in) 1/4
Output drive type Hex
Output retainer type Quick change
Reversible Yes
Starting system Push start

Speed
Free Speed 1300 rpm
Air consumption at free speed 4 l/s

Air information
Air inlet thread size (in) 1/4
Air inlet thread type BSP
Max dynamic air working pressure 6.3 bar
Min hose diam (16 ft hose length) 0.25 in
Min hose diam (5 m hose length) 6.3 mm

Size & Weight
Height (H) 37 mm
Length (L) 250 mm
Width (W) 37 mm
Weight 0.9 kg

Noise & vibrations
Sound Power 94 dB(A)
Sound Pressure 83 dB(A)
Vibration (m/s²) <2.5
Weight 1,32 kg
Dimensions 38,3 × 18,2 × 6,8 cm
